SKYLAB Long Range WiFi IOT/IOE WiFi Module MQTT SSL protocol WU106 MT7687 WiFi smart plug Module

FOB Reference Price:Get Latest Price
US $9-10 / Piece | 10 Piece/Pieces mt7681 wifi module (Min. Order)
Supply Ability:
1000000 Piece/Pieces per Month mt7681 wifi module
Port:
Shenzhen OR Hong Kong
Report Suspicious Activity
Overview
Quick Details
D/C:
WU105-1
Package:
SMD
Model Number:
WU105, WU105
Type:
Logic ICs
Brand Name:
SKYLAB
Place of Origin:
Guangdong, China (Mainland)
Name:
SKYLAB Long Range WiFi IOT/IOE WiFi Module WU105 MT7687 WiFi Module
Maximum Transmit Power:
18dBm
Maximum Sensitivity:
-91dBm
Operating Distance:
200m
Master Chip:
MT7681
Certification:
CE RoHS FCC
Interface:
UART, PWM, GPIO, I2C
Supply Voltage:
3.3V
Maximun Transmit Power:
150Mbps
Packaging & Delivery
Packaging Details
Vacuum packaging and paper box
Delivery Time
Shipped in 3 days after payment

Details for SKYLAB Long Range WiFi IOT/IOE WiFi Module MQTT SSL protocol  WU106 MT7687 WiFi smart plug Module

Product Description

General Description

        The WU106 Wi-Fi Module is a small form-factor, single stream, 802.11b/g/n WiFi module with on-board low power application processor. It is a low cost serial WiFi module, support UART-WiFi - Ethernet data transmission.         The WU106 has been optimized for client applications in the home, enterprise, smart grid, home automation and control that have lower data rates and transmit or receive data on an infrequent basis. The WU106 Wi-Fi Module also enables rapid application development of ultra low power devices with the complete application SW on-chip . This combination makes the WU106 Wi-Fi Module an ideal solution for low power automation and sensor solutions because of its high efficiency and low power consumption (features standby current consumption of less than 10uA while still monitoring peripherals). Furthermore, due to the encryption and tamper detection capabilities of the module it is also suitable for security applications.

        The WU106 Wi-Fi Module can be used to design applications using 802.11b/g/n communication protocols. All features are enhanced by a built-in antenna, external antenna connector and an interface port to the carrier board. This interface port includes power supply pins, GPIO ports and UART ports

        More WU106 details, please click here to send inquiry .

Performance Specifications

SKYLAB UART IOT  Wifi MT7687 Module WU106 IEEE 802.11g Industry Control Wireless Driver

Hardware Features

Model

WU106

Antenna Type

IPEX or PCB Antenna

Chipset solution

 MT7687

Voltage

3.3V±5%

Dimension(L×W×H)

31.3mm*20.3mm*3.2mm

Wireless Features

Wireless Standards

IEEE 802.11b/g/n

Frequency Range

2412GHz---2484MHz

Data Rates

IEEE 802.11b : 1,2,5.5,11Mbps

IEEE 802.11g : 6,9,12,18,24,36,48,54Mbps

IEEE 802.11n :  MCS0--MCS7 @ HT20

                MCS0--MCS7  @ HT40

Receiver Sensitivity

HT40 MCS7 :   -70dBm@10% PER(MCS7)

HT20 MCS7 :   -73dBm@10% PER(MCS7)

54M:           -77dBm@10% PER

11M:           -89dBm@ 8% PER

Modulation Technique

DSSS (DBPSK, DQPSK, CCK)

OFDM (BPSK, QPSK, 16-QAM, 64-QAM)

Wireless Security

WPA/WPA2, WEP, TKIP and AES, WPS2.0, WAPI

Transmit Power

IEEE 802.11n:      15dBm @HT20/40 MCS7

IEEE 802.11g:      16dBm @54MHz

IEEE 802.11b:      18dBm @11MHz

Work Mode

AP/Station mode

Others

Certification

RoHS

Environment

Operating Temperature: -20~55

Storage Temperature: -40~125

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

Features&Applications

Features

1.Compliant to IEEE 802.11b/g/n.

2.1T1R 2.4GHz with support for a 150Mbps PHY data rate.

3. AT command transmission mode and UART transparent

    transmission mode.

4.Smart link.

5.Support TCP,UDP.

6.Support interface: UART, I2C, I2S/SPI, PWM, GPIO.

7. Security: WEP64/128, TKIP, AES, WPA, WPA2, WAPI.

8. Support AP mode and station mode .

9.RoHS compliance meets environment-friendly requirement.

10. UART baud rate: 9600 – 115200bps

11. Size: 31.3mm(L) x 20.3mm(W) x 3.2mm(H) dimension

Applications

1.Network Consumer Device

2.IOT (internet of things)

3.Metering

4.Building Automation

5.Home Automation

6.Home Automation

7.Smart Home Gateway

8.Smart Plug

9.Industry Control



Application Block Diagram

PCB Footprint and Dimensions

Module Pinout
